TYPE C CARD READER

UTC3300

General spec：

1. Interface: Type C (USB30./2.0/1.1)

2. Connection ：RJ45 x 1

3. Network standards:

a. IEEE 802.1 P Layer 2 Priority Encoding

b. IEEE 802.1 Q VLAN tagging

c. IEEE 802.3az-2010 (EEE)

4. USB Lan data transfer rates:

a. Ethernet: 10 Mbps (Half/Full Duplex)

b. Fast Ethernet: 100 Mbps (Half/Full Duplex)、

c. Fast Ethernet: 1000 Mbps (Half/Full Duplex)、

5. Supports pair swap/polarity/skew correction

6. Microsoft NDIS6 Checksum Offload（IPv4，IPv6，TCP,UDP)and Segmentation Task-offload(Large send v1 and Large send v2)support

7. Power consumption: 5V, (power from USB port, no external power required)

8. Power management: support Suspend mode and Remote wake-up Resume

9. Network interface: Female RJ45 jack

10. One Blue LED to indicate Power indicator light

11. The other oneBlue LED flicker to indicate Ethernet port data transmission.

12. Material： ABS & Metal Case

13. System requirement: Android 5.0 or above, Windows 2000 / 2003 / XP / Vista / 7

/ 8 /10 / Mac 10.5 and above

14. Unit Dimensions:（ L x W x H ) 51.2x 23.6 x 16.6mm

15. Unit weight：28.5 g

16.Cable Length: 20 CM
