multi port hub

UTC868

Product Spec：

1. Interface ： Type C 3.1

2. Material：metal case

3. Speed : USB 3.0 up to 5Gbps

4. 4K Video Type C To HDMI Adapter: Mirror or extend your screen and directly stream 4K UHD @ 30Hz or Full HD 1080p video to HDTV, monitor or projector

5.Supports replication mode. HDMI resolution supports 4K* 2k@30hz when using a single interface.

6. Support USB3.0 Card Reader 、U Disk etc other USB3.0 Devices.

7. Support bus-powered mode

8. No external driver installation needed

9. Auto detect card memory

10.When connected to network data, the blue network indicator LED lights will be on, otherwise, LED lights will not be on

11. Support EDID and MCCS pass-through

12. Network standards:

a. IEEE 802.1 P Layer 2 Priority Encoding

b. IEEE 802.1 Q VLAN tagging

c. IEEE 802.3az-2010 (EEE)

13. USB LAN data transfer rates:

a. Ethernet: 10 Mbps (Half/Full Duplex)

b. Fast Ethernet: 100 Mbps (Half/Full Duplex)

c. Fast Ethernet: 1000 Mbps (Half/Full Duplex)

14. Supports pair swap/polarity/skew correction

15. Microsoft NDIS6 Checksum Offload（IPv4，IPv6，TCP,UDP)and Segmentation Task-offload(Large send v1 and Large send v2)support

16. Operating system： Windows 2000 / 2003 / XP / Vista / 7 / 8 /10 / Mac 10.5 and above

17. Support Memory Card ：

              A. SD / SDHC / SDXC / EXTREME SD / EXTREME II SD / EXTREME III SD/ ULTRA SD / ULTRA II SD / ULTRA II SD P PLUS / SD-ULTRA-X /ULTRA SPEED SD / SD PRO / SD ELITE PRO / HS SD / MMC /MMC 4.0 /MMC 4.1/MMC 4.2

              B. Micro SD / micro SDHC / micro SDXC

    18.Unit Dimensions：（ L x W x H ) 156.7 mm x 38.2mm x 15.87 mm

19.Unit  weight： 77g
